Panagon Systems is a trusted manufacturer of aftermarket hydraulic pumps, motors, and replacement components. Since our founding, we’ve specialized in manufacturing discontinued pumps and obsolete parts from brands like Vickers/Eaton. Every component is made in-house in the United States, backed by an 18-month warranty, and guaranteed to meet OEM specifications*.
**Panagon Systems manufactures replacement pumps up to 3000 PSI
PFB 5
The PFB 5 is a fixed displacement axial piston pump originally manufactured by Vickers/Eaton. This pump is known for its volumetric and mechanical efficiencies and comes with an optional extra drain port for vertical, shaft-up installations.PFB 5 Specifications
View our table below for both metric and U.S. product data.Metric
| Displacement per revolution | 10.55 cm3 |
| Max Operating Pressure | Up to 210 Bar |
| Maximum Shaft Speed | 3,600 RPM (with anti-wear hydraulic oil) |
| Maximum Outlet Pressure | 210 Bar (with anti-wear hydraulic oil) |
| Maximum Inlet Pressure | 1 Bar |
| Weight | 5 kg |
| Mounting Type | SAE Flange |
| Special Design Option | Extra Drain Port for Vertical Installation |
| Installation Recommendation | Horizontal Mounting or Vertical “Shaft-Up” |
U.S.
| Displacement per revolution | 0.64 in3 |
| Max Operating Pressure | Up to 3000 PSI |
| Maximum Shaft Speed | 3,600 RPM (with anti-wear hydraulic oil) |
| Maximum Outlet Pressure | 3000 PSI (with anti-wear hydraulic oil) |
| Maximum Inlet Pressure | 15 PSI |
| Weight | 11 lbs |
| Mounting Type | SAE Flange |
| Special Design Option | Extra Drain Port for Vertical Installation |
| Installation Recommendation | Horizontal Mounting or Vertical “Shaft Up” |
Download More Technical Data
Are you looking for more information? Download this PDF below for additional technical information.
Buy a Replacement PFB 5 Pump Today
Start your PFB 5 replacement order today by filling out our convenient online form.
